ID: air.com.ljcreate.virtualelectricalcircuitstrainer
Version: 1.2
Size: 13 Mb
Circuit Builder Screen Preview
How to setup Circuit Builder apk for android
- For Android 4.0 or higher:Please to Settings, look down to Security, and select Unknown sources. Choosing this choice will enable to install apps download from the internet.
- For devices running on lower Android 4.0:
Please go to Settings - open the Applications option, and select Unknown sources, click OK on the popup alert.
Circuit Builder Details
Circuit Builder is designed to be an introduction to constructing and operating electronic circuits. Intuitive controls and layout make Circuit Builder the perfect App for understanding the basics of electrical and electronic circuits. Circuit Builder has been optimised for use on tablets, but also works well on large screen smart phones.Build your own virtual circuits using any combination of electrical components.
The easy to use library of components includes batteries, switches, lamps, resistors (fixed and variable), capacitors, fuses, circuit breakers, buzzers, heaters and motors. Connect components using virtual wires to make a circuit. Put the App into operate mode to see it work. You can even use virtual multimeters to measure voltage, current and resistance.
Circuits can be viewed and built in either component or schematic view.
The component library contains the following items:
Batteries*
1.5V, 6V, 9V and 12V
Switches
Push-to-make, Push-to-break, On-Off, 2-position single-pole, 3-position single-pole,
3-position double-pole, Thermal and Relay
Lamps
6V (5W) clear, 12V (10W) clear, 12V (20W) clear, 12V (20W) red, 12V (20W) yellow and 12V (20W) blue
Resistors
10Ω (5W), 50Ω (5W), 100Ω (5W), 500Ω (5W), 1kΩ (5W), 5kΩ (5W) and 10kΩ (5W)
Variable Resistors
10Ω, 25Ω, 50Ω, 100Ω, 1kΩ and 10kΩ
Capacitors*
500μF, 1mF, 5mF, 50mF, 100mF, 500mF and 1F
Fuses
0.5A, 1A, 1.5A, 2A, 3A, 4A, 5A, 7.5A and 10A
Circuit Breakers
0.5A, 1A, 5A and 10A
Miscellaneous
6V Buzzer, 24V Heater (200W) and a 12V Motor (15W)
*Maximum of four batteries and one capacitor per construction.
What's new in Circuit Builder 1.2
Now fully compatible with Android KitKat (4.4).Download Circuit Builder lastet APK
